UniFi Switch 48 PoE 500W

UniFi Switch 48 PoE 500W
Giá đã có VAT - Bảo hành 12 tháng Để có giá ưu đãi tốt nhất, quý khách vui lòng gửi Email
- Mã SP: US-48-500W | Tình trạng: Còn hàng
Ubiquiti UniFi Switch 48 PoE 500W (US-48-500W)

Liên hệ báo giá tốtTư vấn + báo giá chi tiết về sản phẩm

Ubiquiti UniFi Switch 48 PoE 500W (US-48-500W)

US-48-500W
Dimensions	485 x 43.7 x 374.6 mm
Dimensions	(19.09 x 1.72 x 14.75″)
Weight	6.1 kg
Weight	(13.5 lb)
Networking Interfaces	((48) 10/100/1000 Mbps RJ45 Ethernet Ports
	(2) 1/10 Gbps SFP+ Ethernet Ports
	(2) 1 Gbps SFP Ethernet Ports
Management Interface	(1) RJ45 Serial Port Out-of-Band, Ethernet In-Band
Total Non-Blocking Throughput	70 Gbps
Switching Capacity	140 Gbps
Forwarding Rate	104.16 Mpps
MAC Address Table	16384
Maximum Aggregations	6
Monitoring Sessions	1
Maximum VLANs	255
Power Method	100-240VAC/50-60 Hz, Universal Input
Power Supply	AC/DC, Internal, 500W DC
Max. Power Consumption
Including PoE Output	500W
Excluding PoE Output	64W
LEDs Per Port
RJ45 Data Ports	PoE, Speed/Link/Activity
SFP Data Ports	Speed/Link/Activity
Sound Level*
Fan Level 0	10.7 dBr
Fan Level 1	16.2 dBr
Fan Level 2	19.3 dBr
Fan Level 3	23.6 dBr
ESD/EMP Protection	Air: ± 24 kV, Contact: ± 24 kV
Shock and Vibration	ETSI300-019-1.4 Standard
Operating Temperature	-5 to 40° C (23 to 104° F)
Operating Humidity	5 to 95% Noncondensing
Certifications	CE, FCC, IC
PoE+ Per Port
PoE Interfaces	PoE/PoE+ (Pins 1, 2+; 3, 6-)
PoE Interfaces	24VDC Passive PoE (Pins 4, 5+; 7, 😎
Max. PoE+ Wattage per Port by PSE	34.2W
Voltage Range PoE+ Mode	50–57V
Max. Passive PoE Wattage per Port	17W
24V Passive PoE Voltage Range	20-27V

* Background noise level: 27.5 dBa
