Hardware Specifications | HAT5300-16T |
Capacity | 16 TB |
Form Factor | 3.5″ |
Interface | SATA 6 Gb/s |
Sector Size | 512e |
Rotational Speed | 7,200 rpm |
Interface Speed | 6.0 Gb/s, 3.0 Gb/s, 1.5 Gb/s |
Buffer Size | 512 MiB |
Maximum Sustained Data Transfer Speed (Typ.) | 262 MiB/s |
Mean Time to Failure (MTTF) | 2.5 million hours |
Workload Rating | 550 TB Transferred per Year |
Warranty | 5 Years |
Notes | The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more) |
Supply Voltage | 12 V (± 10%) / 5 V (+10/-7%) |
Active Idle (Typ.) | 4.00 W |
Random Read / Write (4KB Q1) (Typ.) | 7.63 W |
Notes | Power consumption may differ according to configurations and platforms. |
Operating | 5°C to 60°C (41°F to 140°F) |
Non-operating | -40°C to 70°C (-40°F to 158°F) |
Operating | 686 m/s2 {70 G} (2 ms duration) |
Non-operating | 2,450 m/s2 {250 G} (2 ms duration) |
Operating | 7.35 m/s2 {0.75 G} (5 to 300Hz), 2.45 m/s2 {0.25 G} (300 to 500 Hz) |
Non-operating | 29.4 m/s2 {3.0 G} (5 to 500 Hz) |
Operating | -305 m to 3,048 m |
Non-operating | -305 m to 12,192 m |
Operating | 5% to 90% R.H. (No condensation) |
Non-operating | 5% to 95% R.H. (No condensation) |
Size (Height x Width x Depth) | 26.1 mm x 101.85 mm x 147 mm |
Weight | 720 g |
Certification | CE |
EAC | |
BSMI | |
RCM | |
KC | |
ICES | |
UKCA | |
TUV | |
UL | |
RoHS |
